Heat from solar power.
enhelios delivers sustainable process heat from concentrated solar thermal energy. A patented parabolic-dish concentrator design provides clean, cost-effective heat.
Get in touchGreen process heat for sustainable products
Scalable heat control
A concentrated solar energy solution with a parabolic-dish concentrator design for clean, cost-effective thermal energy.
High efficiency
Designed to minimise the total cost per unit of energy delivered. Powerful and economical.
Small footprint
Easy to install, calibrate and maintain. Designed for autonomous operation in demanding environments.
From the sun to process heat
The parabolic reflector dish, made of durable aluminium reflectors, is mounted on a tracker resting on a steel mast. It follows the sun across two axes and maximises the capture of solar radiation. The heated thermal fluid flows through a heat exchanger and generates high-temperature steam or other fluids with high temperature and enthalpy.
Versatile applications
SME production and industry
Clean thermal energy for industrial processes and manufacturing.
District heating
Grid-connected heat supply for residential and commercial districts.
Large buildings
Efficient process and space heating for residential, office and hall spaces.
ENH-1G to ENH-4G
| Specifications | ENH-1G | ENH-2G | ENH-3G | ENH-4G |
|---|---|---|---|---|
| Mirror rings | 1 | 2 | 3 | 4 |
| Mirror surface | 5.10 m² | 14.24 m² | 27.30 m² | 43.20 m² |
| Thermal output | 3.12 kWth | 8.71 kWth | 16.71 kWth | 26.44 kWth |
| Net weight | 966 kg | 1,121 kg | 1,568 kg | 1,848 kg |
| Parabolic mirror | Aluminium | |||
| Receiver | Cavity receiver | |||
| Heat transfer fluid | Glycol water or thermal oil | |||
| Tracking accuracy | < 0.1° | |||
All power figures are peak thermal outputs (kWth) under design conditions. The concentrators generate heat only, no electricity.
Ready for green process heat?
Concentrated solar thermal for industry, districts and large buildings. Let's talk about the right concept.
